⇠ MD1023
Specification
| mm | inch | |
|---|---|---|
| (A) DIAMETER: | 432 | 17.01 |
| (B) MINIMUM THICKNESS: | 37 | 1.46 |
| (B) THICKNESS: | 45 | 1.77 |
| (C) REGISTER: | 131 | 5.16 |
| (D) HEIGHT: | 130 | 5.12 |
| (E) PCD: | 168 | 6.61 |
| (F) STUD HOLE DIAMETER: | 19 | 0.75 |
| (F) STUD HOLE QTY: | 12 | |
| BOX HEIGHT: | 150 | 5.91 |
| BOX LENGTH: | 452 | 17.80 |
| BOX WIDTH: | 452 | 17.80 |
| ECE R90: | APPROVED | |
| EXTRA HOLES: | 3T | |
| WEIGHT | 36.00 kg |
Cross References
| BARCODE GTIN-13: | 5055677301511 |
| OEM: | - SOLID VERSION AVAILABLE MD1023S, 28050090, 6347297, 6347297NFA, 81.50803-0023, 81.50803-0038, 81.50803-0040, 81.50803-0046, 81.50803.0023, 81.50803.0033, 81.50803.0038, 81.50803.0040, 81.50803.0046, 81.50803.3023, 81.50803.3040, 81508030023, 81508030036, 81508030038, 81508030040, 81508030046, 81508033023, 81508033040, N508030038, N508030040 |
| 3G: | AD1145 |
| ALT REF: | 09738220, 14122A, 31672001000, 31672001090, 360204200131, 3651121292, 40-43917, 43908, 43908, 44F3317, 44F3317, 481119, 48122, 50554, 51052, 77717478, 81508030031, 955780, 987218, CB-76621, CF104678, CSD17A30, CWD1001, CWD354, II37784, II67784, M44D76621, MN1108, NCA95396, NCA95396, PL12866, TTBR1540, WDR579 |
| AMIPART: | AM8060 |
| APEC: | DSK7011 |
| ATP: | 115-0003-19 |
| AXLETECH: | 321801316ES |
| BERAL: | BCR214A |
| BORG & BECK: | BBD32629 |
| BREMBO: | 09.7382.20, 09.9435.10 |
| CARGOPARTS: | FL-MN1060 |
| CEI: | 215.082, 215082 |
| COMLINE: | ADC9028V |
| DON: | CVD579 |
| DT: | 3.62053 |
| DURABRAKE: | 76621 |
| EBS: | 28.26.1000 |
| EFI: | ECD146 |
| EMMERRE: | 960321 |
| EUROPART: | 2072 432 004 |
| FEBI: | 12731 |
| FERODO: | FCR181A, FCR214A |
| FRAS-LE: | FHDI00038 |
| GRANNING: | 14122 |
| GRANTEX: | 251.45.0006, 251450006 |
| ISOTECH: | 601023V |
| JURATEK: | MAN106, MD106 |
| JURID: | 567408J |
| KNORR BREMSE: | K069799 |
| MARATHON: | RB068 |
| MERITOR: | M44D76621, MBR5057 |
| MIDLAND: | MPBR76621 |
| NAPA: | NTBD7011 |
| NEW FLYER: | 6347297 |
| PE: | 036.121-00A, 03612100A |
| PROLEAD: | 481119 |
| REPLACES: | ER1042, MAN1019, MD1019 |
| ROADLINK: | 2008, 3108 |
| SAM REV: | 1608MN, 1612MN, 1612MN |
| SAUER: | S0790503810 |
| SBP: | 02-MA03 |
| TEMPLIN: | 03.110.0922.050, 03.110.0922.090, 031100922050 |
| TEXTAR: | 93087200 |
| TODD: | 8060006 |
| TRP: | 1962305 |
| TRUCKTEC: | BD1011 |
| TTC: | 80242, 80242, 8309 |
| UNIVERSAL: | KLTE0033 |
| VALEO: | 187052 |
| WEBB: | 55040P, 55040P-99 |
| WINNARD OLD P/N: | MAN1023, MN1023 |
| ZIMMERMANN: | 360.6390.00 |
