Specification

mm inch
(A) DIAMETER: 410 16.14
MP/32/2 INTERNAL RADIUS: 200 7.87
MP/32/2 LENGTH: 192 7.56
MP/32/2 No. OF RIVETS: 64 2.52
MP/32/2 QUANTITY PER SET: 8 0.31
MP/32/2 RIVET SIZE: 8x18
MP/32/2 THICKNESS: 17.0/11.8
MP/32/2 WIDTH: 180 7.09
WEIGHT 7.50 kg

Cross References

OEM: 2V5698511A, 3464231010, 3464232910, 3464239610, 4211530, 6174231111, 6174231211, 6174231330, 6174231430, 6174232711, 6174232811, 6174235110, 6174235111, 6174235911, 6174236011, 6174236311, 6174236411, 6174237111, 6174239311, 6594232510, 6594234010, 6594234110, 81.50220.0524, 81.50220.0551, 81.50220.0664, 81.50220.0665, 81.50221.0058, 81.50221.0181, 81.50221.0219, 81.50221.0441, 81.50221.0451, 81.50221.0526, 81.50221.0645, 81.50221.0771, 81.50221.0784, 81.50221.0809, 81.50221.0850, 81.50221.0855, 81.50221.0906, 81.50221.0908, 81.50221.0949, 81.50221.6077, 81.50221.6097, 81.50221.6114, 81502200551, 81502210441, 81502210526, 81502210553, 81502210645, 81502210771, 81502210784, 81502210849, 81502210850, 81502210855, 81502210908, 81502216077, 81502216078, A0004211530, A3464239610, A617 423 2711, A6174231111, A6174231211, A6174231330, A6174232711, A6174235110, A6174235111, A6174235911, A6174236011, A6174236311, A6174236411, A6174237111, A6174239311, A6174239411, A6594232510, A6594234110, B4203927
ALT REF: 08610100, 1949509, 1949510, 6174239411, 6594232410, 81502216071, 81502216097, 81502216098, A6174231430, MP 32/2, MP322A7100, MP322A7115, MP322B7115
ALTREF: MP 32 2
DT: 4.91131
FERODO: K19487.0TC
JURID: 1949501070
MERITOR: MBLK2200
TEXTAR: 1949502, 1949507, 1949511
WVA: 19487, 19495, 1949504, 1949509, 1949512
