WP201

Reduce the amount of time you spend searching for and ordering the parts your business needs. Use our online catalogue to search for parts by keyword, dimensions, cross-references, and vehicle applications.

Login | Register

Notes

  • Winnard ECE R90 approved. Supplied with fitting bolts, WL065 & WL067 wear leads.

Specification

mm inch
BOX HEIGHT: 68 2.68
BOX LENGTH: 248 9.76
BOX WIDTH: 168 6.61
HEIGHT: 80 3.15
LENGTH: 164 6.46
THICKNESS: 20 0.79
WEIGHT 2.20 kg

Cross References

BARCODE GTIN-13: 5055677303324
OEM: 004 420 81 20, 0044208120, 005 420 74 20, 0054207420, 006 420 45 20, 0064204520, 2E0698451A, 2E0698451B, A0044208120, A0054207420, A0064204520, A0064244540
3G: AD8481
ALT REF: 10916709, 11-1318, 13046038422, 363702161475, 4862603AA, 8432-D1318, BP1318, CV20905016, DX1318W, FSL1779, MKD1318, PAD1517
ATE: 13 0460 3842 2, 13.0460-3842.2
BLUE PRINT: ADU174240
BOSCH: 0 986 494 122
BREMBO: P 50 060
COMLINE: ADB01575, CBP01575
DELPHI: LP1984
DT: 4.91901
EBS: EKBP.201
FEBI: 16709
FERODO: FVR1779, FVR4429
HELLA: 8DB 355 005 541, 8DB 355 005-541
JURATEK: JCP124
MAGNETI MARELLI: 363700036027
MINTEX: MDB2805
ROADLINK: 1318.10
TEXTAR: 2921701, 2921702
TRW: GDB1699
UNIVERSAL: KLTE0283
VALEO: 873190
WVA: 29217
ZIMMERMANN: 29217.205.1
