RW/28/30/31/1

Reduce the amount of time you spend searching for and ordering the parts your business needs. Use our online catalogue to search for parts by keyword, dimensions, cross-references, and vehicle applications.

Login | Register

Notes

  • AN AXLE SET WILL CONTAIN 4 x RW/28/2 + 2 x RW/30/1 + 2x RW31/1 - IF NOT IN STOCK THEN ORDER HALF A SET OF RW/28/2 and HALF A SET OF RW/30/31/1

Specification

mm inch
FITS DRUM DIAMETER: 410 16.14
No OF RIVETS: 96 3.78
RIVETS: 8x15 7338C Fully Tubular
RW/28/1 QTY PER SET: 4
RW/30/1 QTY PER SET: 2
RW/31/1 QTY PER SET: 2
WIDTH: 180 7.09
WEIGHT 9.40 kg

Cross References

OEM: 1906371, 1906372, 1906373, 1906404, 1906407, 1906408, 1906409, 1906431, 2991624, 2991627, 2991628, 2991913, 2991914, 2991915, RBSK1523.M
ABEX: B2741, B6741
ALT REF: RW 28/30/31/1
ALTREF: RW 28 30 31 1
FERODO: K19714.0, K19714.2
TEXTAR: 1971401, 1971410
WVA: 19555, 19556, 19714, 19715
